UkuLayisha ngokuzenzekelayo kunye nokuLayishwa kweNqaba yokuKhanya ngeMobile

I-Automatic Loading and Unloading Mobile Lighting Tower ifaka i-automated loading and unloading structure, ukuphelisa imfuno yee-cranes, i-forklifts, okanye ezinye iimatshini ezincedisayo. Inokuhlala ngokukhawuleza, isombuluke, isonge, kwaye izigcine isebenzisa isakhiwo sayo kuphela. Ukuthuthwa kwayo okufanelekileyo kunye nokuhanjiswa okusebenzayo kwisiza kunciphisa kakhulu abasebenzi kunye nexesha lokulungiselela.

Izinto Eziluncedo Ezingundoqo

UkuZilayisha ngokukhawuleza kunye nokusasazwa

Eyakhelwe ngaphakathi yokulayisha kunye nenkqubo yokukhulula

Akukho zixhobo zokuphakamisa zangaphandle ezifunekayo

Umsebenzi womntu omnye wokuthutha kunye nokumisela

Ixesha lokusasaza ≤ 180 imizuzwana

Ukusebenza okuphezulu kwe-360 ° Ukukhanyisa

4 × 1000W izibane ezikhanyayo ze-LED

I-360 ° iguquguquka yokukhanyisa ukukhanya

Uluhlu lokukhanya ukuya kwi-120 yeemitha

Ukukhanya okukhanyayo ≥ 380,000 lm

Izibane ezizinzileyo, ezincitshiswe ilitha kwimisebenzi yasebusuku

Ukuguquguquka okuqinileyo kwangaphandle

IP67 iintloko zezibane ezingangeni manzi

Ukumelana nomoya ukuya kwiNqanaba lesi-8

Isakhiwo esingangenwa luthuli kunye ne-corrosion-resistant

Isebenza emvuleni, kwikhephu, kwisanti, nakubushushu obugqithisileyo

Ixesha elide lokuSebenza kunye namandla aguquguqukayo

Ijenereyitha yeHonda 4-stroke (5–5.5kW)

Ixesha eliqhubekayo lokusebenza ukuya kwiiyure ezingama-25

Imowudi yamandla amabini: ijenereyitha okanye i-220V yokubonelela ngokuyintloko

Inkqubo yokuSebenza ngobuchule

Iphaneli yokulawula ye-LCD + ulawulo olude ngaphandle kwamacingo (≥120m)

Ukuphakama kwemasti ehlengahlengiswayo ukuya kuthi ga kwi-7.3m

Ukunyusa ngokukhawuleza: ≤50s phezulu / ≤35s phantsi

I-interface yokusebenza ekhuselekileyo nelula

IiParameters zobuGcisa

1. I-Voltage elinganisiweyo: AC 220V, 50Hz

2. Amandla eNtloko yesibane: 4 × 1000W umthombo wokukhanya we-LED

3. Ukukhanyisa: Xa intloko yesibane iku-90° emhlabeni,

Ukukhanya kuya kuba ngaphezulu kwe-6000 Lx kwiimitha ezingama-20 ukusuka kwiziko lokukhanya,

ngaphezulu kwe-1000 Lx kwiimitha ezingama-50,

kwaye ngaphezu kwe-200 Lx kwi-120 yeemitha.

4. Amandla eJenereyitha: 5～5.5kW

5. Indlela yokuPhakamisa yeNqaba yokuKhanya: I-Pneumatic

6. Ubukhulu bokuphakama koBuphakamo: 7.3m

7. Iklasi yoKhuseleko lweNtloko yesibane: IP67

8. Imodi yokuQalisa: Ukuqalisa ngesandla + Ukuqalisa koMbane

9. Ixesha eliqhubekayo lokuSebenza: iiyure ezingama-25

10. Ixesha lokuphakamisa: Ukunyuka ≤ 50s / ukwehlisa ≤ 35s

11. Uluhlu loLungiso lweNtloko yesibane: Ngokuthe nkqo 0–135 ° / Ukuthe tye 0–360°

12. Isethi yeGenereyitha: iHonda, i-4-stroke, i-air-cooled

13. Ukufuduswa: 389CC

14. Ukusetyenziswa kwamafutha: 1.7L/h; Umthamo weTanki yeFuel: 45L

15. I-Generator Output Voltage: AC 220V, 50Hz

16. Ubunzima obupheleleyo: 600KG

7. Imilinganiselo iyonke:

Isetyenziswe: ≤ 2500×1500×7300mm

Igcinwe: ≤ 1800×1400×2500mm

18. Guardrail Light Power: 2 × 28W

19. Ixesha lokuLayishwa kweNqaba kunye nokuLahla: ≤ 180s

20. I-Radius ye-Lighting Coverage: 120m

21. Ukutshintshwa kweentloko zesibane kunye nokuphakanyiswa kwepali kunokulawulwa ngokubonisa i-LCD kunye nokulawula okude ngaphandle kwamacingo; umgama wolawulo olukude ＞ 120m.

Iimpawu zokuSebenza

1. Izindlu eziphambili ze-Automatic Loading and Unloading Mobile Lighting Tower ixhotyiswe ngesakhiwo sokukhiya kwaye igqitywe nge-powder coating ukukhusela onke amacandelo angaphakathi. Imodyuli yokulawula injini ekrelekrele ibonelela ngokubeka iliso okubanzi kunye nokhuseleko olusebenzayo lwe-injini, iququzelela ukugcinwa kwemihla ngemihla. Iicaster ezine ezisongekayo ezisongekayo zifakwe emazantsi ukuze zihambe bhetyebhetye.

2. Ukukhanya okuphambili kwamkela i-4 × 1000W imithombo yokukhanya ye-LED, inikezela ukukhanya okuphezulu kunye noluhlu olubanzi lokugubungela umgama omde kunye nokukhanya okufutshane. Ubomi benkonzo yomthombo wokukhanya budlula iiyure ezili-10,000, nto leyo eyenza ukuba ifaneleke kakhulu kwizibane ezinkulu zokusebenza zangaphandle.

3. Inqaba ifakwe i-pneumatic lifting mast eyenziwe nge-6063 aluminium alloy kunye ne-hard anodized surface unyango lokumelana nokugqwesa okugqwesileyo, kunye nokuphakama kokuphakama kweemitha ezi-7.3. Iintloko zezibane ezine zixhasa ukujika kombane ngokuthe nkqo ukusuka ku-0 ° ukuya kwi-135 ° kunye ne-360 ° ulungelelwaniso lwe-engile ethe tye, ukufikelela kwindawo epheleleyo ngeradiyasi yokukhanyisa engekho ngaphantsi kwe-120 yeemitha.

4. Ixhaswe yisethi ye-generator, iyunithi inokusebenza ngokuqhubekayo kwiiyure ze-25 kwi-tank epheleleyo yamafutha. Isenokuqhagamshelwa kwi-220V AC yombane ongundoqo wokukhanyisa ixesha elide apho ukhoyo umbane kamasipala.

5. Ukuxhotyiswa ngepaneli edibeneyo yokusebenza okubonakalayo kunye nokutshintsha kokulawula ngesandla, isixhobo sibonisa ukusebenza okulula, okukhuselekileyo nokuthembekileyo.

6. Ngesakhiwo esipheleleyo se-compact kunye nokusebenza okuzinzile, inqaba ixhotywe ngemilenze emine yokuxhasa intonga yombane, eyenza ukuba iyunithi ephambili iphakanyiswe ngokudibeneyo ngaphezu kwe-1000 mm. Ibonelela ngenkxaso ezinzileyo nelungeleleneyo kwiindawo zokwakha ezingalinganiyo, isebenza ngokuqhelekileyo phantsi kweemeko ezingqongileyo kunye neemeko zemozulu, kwaye ifikelela kwiNqanaba lesi-8 lokumelana nomoya.

7. Uyilo oluphuculweyo lwesakhiwo luqinisekisa ukuhamba lula kunye nokuthutha. Ixhasa ukuzilayisha kombane kunye nokuzothula kwiibhedi zemithwalo yelori, ebonisa umbono woyilo olwenziwe ngumntu.

8. Iyonke i-flux ekhanyayo yeentloko zezibane: ≥380,000 lm; Inqanaba lengxolo: phantsi kokusebenza okuqhelekileyo, ingxolo yokusebenza ilinganiswe kwiimitha ezi-7 malunga ne-injini ayikho ngaphezu kwe-62 dB.

9. Iseti ye-2 × 28W izibane zokugada zifakwe malunga neyunithi ephambili, ebonisa ukusebenza kakuhle kwamanzi kunye nothuli.

Ububanzi beSicelo

Oku kuLayishwa ngokuzenzekelayo kunye nokuLayishwa kweNqaba yokuKhanya kweMobile ilungele uluhlu olubanzi lweemeko kwaye ihlangabezana nemfuno yendawo enkulu, ukukhanya okukhanyayo kwiindawo ezininzi. Isebenza kwimisebenzi eyahlukeneyo yolwakhiwo olukhulu, ukusebenza kwemigodi, ukuhlola intsimi kunye neeprojekthi zokwandiswa kwefektri, ukubonelela ngokukhanya okwaneleyo kumsebenzi obanzi ebusuku okanye kwiimeko eziphantsi zokukhanya ukuqinisekisa ukusebenza kakuhle kokwakhiwa kunye nokhuseleko lokusebenza.

Okwangoku, isebenza njengesixhobo sokukhanyisa esiyimfuneko kwimishini yokuhlangula ngokukhawuleza. Isetyenziswa ngokubanzi ekugcinweni nasekulungisweni okungxamisekileyo kwamandla, unxibelelwano kunye nezibonelelo zendlela, ukusingatha indawo yeengozi zequbuliso, ukuthintela izikhukhula kunye nokulwa nezikhukhula, kunye nokuhlangula kunye nokuhlangula kwiintlekele. Inikezela ukukhanya okuzinzile kwendawo enkulu yongxamiseko ukuxhasa amaqela angxamisekileyo ekwenzeni umsebenzi wokuhlangula kunye nokusingatha iingozi ngokufanelekileyo.
